Laser Engraving Jig Bundle, Dog Tag Name Tag Metal Card Coaster, LightBurn Ready SVG DXF, Batch Alignment Templates

Batch engraving is faster when the physical registration is repeatable. This Laser Engraving Jig Starter Pack gives makers dimensioned SVG and DXF jig geometry for common small-item production, plus multiple fit tolerances so you can test your real blanks instead of assuming one universal clearance.

5 PRODUCTION JIG TYPES
• 50 x 29 mm dog tag — 6-up
• 77 x 39 mm name tag — 6-up
• 85.6 x 54 mm metal business card — 4-up
• 4-inch round coaster — 4-up
• 4-inch square coaster — 4-up

3 FIT OPTIONS FOR EVERY JIG
• +0.0 mm nominal opening
• +0.2 mm total clearance
• +0.4 mm total clearance
A separate clearance test strip is included so you can test scrap material before production.

FILES INCLUDED
• 15 production SVG files
• 15 matching DXF files
• Clearance Test Strip SVG + DXF
• Setup and safety PDF guide
• Dimension manifest
• Commercial-use license for physical finished products

LIGHTBURN WORKFLOW
SVG and DXF files can be imported into LightBurn and other compatible laser-design software. Verify import scale, assign cut geometry to your own cut layer, frame the job, and test one sacrificial blank before batch production. Machine power and speed settings are intentionally not included because safe settings vary by laser, lens, focus, material, coating and maintenance condition.

IMPORTANT FIT NOTE
Blank dimensions vary by supplier. Measure your actual item with calipers and run the included clearance test before cutting a production jig. Confirm the listed board dimensions fit your usable laser work area.

LICENSE
You may use these digital jig files in your own production workflow and sell physical finished goods made with them. Do not resell, share, redistribute or re-list the digital jig files.
